Rikon Benchtop Jointer 20-800HSP with 8'' Insert Cutter Head

Item #
77723

Tables feature Synthetic Polymer Coating for low-friction glide—helical-style head has double-sided carbide insert cutters that can be rotated and replaced.

More details
$999.99
How do you want your item?
Delivery
Check In-Store Availability
As soon as today
As soon as today
Check availability in your nearest store

Expert Advice

Mastering woodwork: Expert insights revealed

Contact Us

Satisfaction Guarantee

Enhance your product’s protection and durability

Click Here

Family Run

Passion passed down through generations

Read More

Crafting with Wood: Turn Your Ideas into Reality

Create with wood! Our premium materials make your projects come to life...Read More

The Rikon #20-800HSP 8'' Benchtop Jointer features a low-friction Synthetic Polymer Coating on the tables and a helical head with six rows of carbide insert cutters. Each insert cutter has two edges for an exceptionally smooth, flat jointed surface. The 16 cutters can be rotated to expose a fresh edge, and when it comes time to replace them (see #53059), there is no need to level the knives as with a traditional jointer. The jointer itself features rigid, all-metal construction, machined aluminum tables with integral extensions that pull out for up to 51-1/2'' of support, a quick depth setting mechanism with scale, and an adjustable fence that tilts from 90° to 45°. It also comes with a spring-loaded safety guard, dust port, an easily accessible front-mounted on/off switch and two push blocks.

Rikon 20-800HSP 8'' Benchtop Jointer Details:

  • Powerful 10-amp motor
  • Helical cutterhead for a smooth cut
  • All steel construction for durability
  • Carbide insert knives can be rotated to expose a fresh edge
  • Large 8-3/16'' x 30-1/2'' table with slide-out extensions for up to 51-1/2'' of length
  • 4-3/8''H x 19-1/4''L fence angles from 90° to 45°
  • Replacement carbide cutters available (#53059, sold separately)

(1) Rikon Benchtop Jointer 20-800HSP with 8'' Insert Cutter Head
(2) Push blocks
(2) Hex wrenches
(1) Dust port

More Information
Brand Rikon
Manufacturer Part Number 20-800HSP
Weight 57.75
Tech Spec
  • Brand: Rikon
  • Manufacturer Part Number: 20-800HSP
  • Motor Speed (No Load): 20,000 RPM
  • Motor Amps: 10
  • Volts: 120V, 60 Hz
  • Fence Size: 19-3/4'' x 4-3/8''
  • Fence Tilt: 90° – 135°
  • Table Dimensions (L x W): 30-1/2'' x 8-3/16''
  • Cutterhead Diameter: 2''
  • Cutterhead Speed: 12,000 RPM
  • Number of HSS Inserts (2-sided): 16
  • HSS Insert Size: 14.2mm x 14.2mm x 2mm
  • Number of Insert Rows: 6
  • Maximum Depth of Cut: 1/8''
  • Maximum Cutting Width: 8''
  • Minimum Length of Stock: 10''
  • Minimum Width of Stock: 3/4''
  • Minimum Thickness of Stock: 1/2''
  • Dust Port Diameter (OD): 4'' and 2-1/2''
  • Dust Collection Minimum CFM: 100
  • Noise Level (No Load) at 3 Feet: <100dB
  • Overall Height: 13''
  • Overall Width: 18-3/4''
  • Overall Length (extended): 51-1/2''
  • Base Size: 19'' x 11-1/4''
  • Net Weight: 49 lbs.
  • Shipping Weight: 61 lbs.
